4-20ma Profibus Converter Conversion Device Converter
NCS-FI105 fieldbus to current Converter is used to convert fieldbus signals to conventional analog signals. It can receive fieldbus signals, and convert them to 4-channel 4~20mA analog signals. NCS-FI105 is the converter between fieldbus system and control valve/other actuator.
4-20ma Profibus Converter Conversion Device Converter
Product overview
NCS-F1105 fieldbus to current Converter is used to convertfieldbus signals to conventional analog signals. lt can receivefieldbus signals, and convert them to 4-channel 4~20mA analogsignals.NCS-Fl105 is the converter between fieldbus systemand control valve/other actuator.NCS-Fl105 is an intelligent instrument and complies with FF Fieldbus Specification.lt can be interlinked with several FF equipment. Abundant function blocks are integrated into NCS-F1105,and soit can complete not only the generalmeasuring but also the complex controlling strategy. Accordingto the requirement and actual application environment, theusers can choose different function blocks to implementdifferent function.
NCS-F1105 utilizes digital technology, which simplifies theinterface between the control center and the field equipment.And so the expense of installing, running and maintenance canbe reduced.
Features
Number of channels:4
Output of signal:4-20mA
Bus signal:31.25kbit/s
Power:9-32VDC
Current consumption(static):≤ 14mA
Details
Parameters
Parameter | Value |
Input signal | 4～20mA |
Channels | 4 Channels |
Current output | NPN collector output |
Power supply | 9 ～ 32 VDC ;Current Dissipation (static): ≤ 14mA |
Fieldbus Signal | Communication Baudrate 31.25kbit/s, current-mode |
Insulation | Between housing and terminal board: |
500 Vrms (707 VDC) | |
Display | 6 bits digital number and 5 bits characters LCD display (Optional) |
Temperature range | - 40 ～ 85℃ （No display） |
- 30 ～ 70℃ （display） | |
Humidity Range | 0% ～ 100% RH |
Start Time | ≤ 5s |
Protection grade | IP 65 |
EMC | Designed to comply IEC 61000 |
Size
Installation
For installation of NCS-Fl105 converter, three types of bracket(pipe mounting flat bracket, plate mounting angle bracket andpipe mounting angle bracket)are provided. Accordingly thereare three installation methods as the following.
The installation of pipe mounting flat bracket: the typica!installation as shows. Fix NCS-Fl105 converter in flatbracket using four bolts provided, and then fix the flat bracket onthe vertical pipe in Ф50mm around through the U-shape boltprovided.
The installation of plate mounting angle bracket: the typicalinstallation as shows. Fix NCS-Fl105 converter inangle bracket using four bolts provided, and then fix the anglebracket on the plate through the M10 bolt not provided.
The installation of pipe mounting angle bracket: the typicalinstallation as shows. Fix NCS-Fl105 converterin angle bracket using four bolts provided, and then fix the anglebracket on the horizontal pipe in ф50mm around through theU-shape bolt provided.
